Overview

Hey guys! Let's talk about making life easier when it comes to manufacturing. The main goal here is to capture all those little (and big) manufacturing considerations and CM frustrations right into circuit-synth. Imagine a world where manufacturing is smooth sailing – that's what we're aiming for! Think of all the times you've wanted to pull your hair out dealing with Gregor or any CM. We need to lock down all that critical information so that circuit-synth gives us a fantastic manufacturing experience. This means clear, concise, and complete documentation that leaves no room for error or misinterpretation. The entire process should be streamlined, from initial design to final product, with every step clearly defined and easily accessible.

This involves creating a robust system within circuit-synth that anticipates potential manufacturing issues and provides solutions proactively. By integrating all relevant data, including component specifications, assembly instructions, and testing procedures, we can significantly reduce the back-and-forth communication with CMs. The result is a faster turnaround time, reduced costs, and a higher quality end product. Furthermore, this system should be flexible enough to adapt to the specific requirements of different CMs, ensuring compatibility and ease of integration regardless of the chosen manufacturing partner. Ultimately, the goal is to empower users to manage the entire manufacturing process from within circuit-synth, providing a seamless and efficient workflow that minimizes errors and maximizes productivity.

CM Frustrations to Solve

Alright, let's dive into the nitty-gritty. What are the pain points we're trying to fix? Here's a rundown of the CM frustrations we need to tackle head-on:

Documentation Issues

  • Missing assembly instructions: How many times have you scratched your head wondering how something goes together? We need crystal-clear instructions.
  • Unclear component orientation: Is that diode facing the right way? Let's eliminate the guesswork.
  • Incomplete BOM (missing manufacturer part numbers): Hunting down part numbers is a drag. A complete BOM is a must.
  • No test procedures: How do we know it works? We need defined test procedures.
  • Missing component alternates: When your primary component isn't available we need a replacement ready to go.

Communication Issues

  • Back-and-forth on component substitutions: Ain't nobody got time for endless emails about swapping parts.
  • Clarifications on special assembly requirements: If something needs extra care, let's make it obvious.
  • PCB stackup specifications unclear: Specifying PCB stackup requirements can be tricky. Clear and concise PCB stackup specifications are essential for the successful fabrication of printed circuit boards.
  • Solder mask/silkscreen requirements: Solder mask and silkscreen specifications play a crucial role in the manufacturability and functionality of PCBs. Accurate and detailed specifications are necessary to ensure proper solder application, component placement, and clear identification of board features.

Process Issues

  • Component availability changes after quote: Getting a quote and then finding out parts are out of stock? Super frustrating.
  • Last-minute design changes: We all know how often designs will suddenly change, we have to be ready.
  • Missing Gerber files or incorrect versions: Ensuring that the correct Gerber files are used is essential for proper manufacturing and assembly. Version control is critical for managing changes, preventing errors, and maintaining consistency throughout the production process.
  • No clear acceptance criteria: What does "good" even mean? We need unambiguous acceptance criteria.

Solution: Manufacturing Package Generator

So, how do we solve these headaches? By auto-generating complete manufacturing documentation. Here’s the breakdown:

1. Assembly Documentation

  • Pick-and-place files with correct orientation: These files ensure that components are accurately placed on the PCB during assembly. Correct orientation is vital to prevent functional errors and ensure proper circuit operation.
  • Assembly drawings with component callouts: Assembly drawings provide visual guidance for component placement and orientation. Clear callouts and markings are important for assemblers to identify and correctly install each component.
  • BOM with alternates (pre-approved substitutions): A comprehensive BOM that includes pre-approved alternates can help mitigate component availability issues. Having alternates readily available can prevent delays and keep the manufacturing process on track.
  • Special instructions (press-fit, hand assembly, etc.): Special instructions communicate any unique requirements or considerations for specific components or assembly processes. These instructions are critical for ensuring that complex or sensitive components are handled correctly.
  • Component placement photos (reference images): Reference images provide visual aids that can help assemblers accurately place components, especially when dealing with small or complex parts. These photos serve as a valuable reference for ensuring correct orientation and placement.

2. Fabrication Documentation

  • Complete Gerber set (all layers): A complete Gerber set includes all the necessary files for PCB fabrication, such as copper layers, solder mask, and silkscreen. Ensuring all layers are present and accurate is essential for proper board manufacturing.
  • Drill files (PTH and NPTH): Drill files specify the location and size of all drilled holes on the PCB, including plated-through holes (PTH) and non-plated-through holes (NPTH). Accurate drill files are necessary for proper component mounting and electrical connectivity.
  • Stackup specification (impedance-controlled): The stackup specification defines the arrangement and properties of the various layers in the PCB. Impedance control is important for high-speed signals to prevent signal reflections and ensure signal integrity.
  • Solder mask/silkscreen specifications: Solder mask specifications define the areas of the PCB that should be covered with solder mask to prevent shorts during soldering. Silkscreen specifications define the markings and labels on the PCB for component identification and branding purposes. Accurate specifications are essential for proper board functionality and aesthetics.
  • Board outline and panel requirements: The board outline defines the physical dimensions and shape of the PCB. Panel requirements specify how multiple PCBs should be arranged on a single panel for efficient manufacturing. Clear and accurate specifications are necessary for proper board fabrication and assembly.

3. Testing Documentation

  • Test procedures (functional, electrical): Test procedures outline the steps and criteria for verifying the functionality and electrical performance of the assembled PCB. Comprehensive test procedures are essential for identifying and correcting any manufacturing defects.
  • Test points and fixture requirements: Test points are specific locations on the PCB that are used for testing purposes. Fixture requirements define the type of fixtures or equipment needed to perform the tests. Clear test points and fixture requirements streamline the testing process and ensure accurate results.
  • Acceptance criteria (pass/fail thresholds): Acceptance criteria define the acceptable range of values for each test parameter. These criteria are used to determine whether the PCB passes or fails the test. Clear and well-defined acceptance criteria ensure consistent quality control and prevent subjective interpretations.
  • Known issues and workarounds: Documenting known issues and workarounds can help troubleshoot potential problems during testing and assembly. This information prevents delays and minimizes the impact of known defects.

4. Logistics Documentation

  • Component sourcing (DigiKey/JLCPCB part numbers): Providing specific part numbers from reputable suppliers like DigiKey and JLCPCB ensures that the correct components are used during assembly. This reduces the risk of errors and ensures component compatibility.
  • Lead times and availability: Monitoring lead times and component availability can help prevent delays in the manufacturing process. This information allows for proactive planning and ensures that components are available when needed.
  • Packaging requirements: Packaging requirements specify how the assembled PCBs should be packaged for shipping and storage. Proper packaging protects the boards from damage during transit and ensures they arrive in good condition.
  • Shipping instructions: Shipping instructions provide details on how the assembled PCBs should be shipped, including carrier preferences, shipping address, and any special handling requirements. Clear shipping instructions ensure timely and accurate delivery of the finished products.

Integration with circuit-synth

Here’s how it looks in action:

circuit.generate_manufacturing_package(
    cm_provider="screaming_circuits",
    volume=100,
    output_path="manufacturing/"
)

# Generates:
manufacturing/
├── assembly/
│   ├── BOM_with_alternates.csv
│   ├── pick_and_place.csv
│   ├── assembly_drawing.pdf
│   └── special_instructions.md
├── fabrication/
│   ├── gerbers/
│   ├── drill_files/
│   ├── stackup.pdf
│   └── fabrication_notes.md
├── testing/
│   ├── test_procedure.md
│   ├── test_points.csv
│   └── acceptance_criteria.md
└── README.md  # Complete manufacturing guide

CM Profile System

Different CMs march to the beat of their own drum, so we need profiles:

cm_profiles = {
    "screaming_circuits": {
        "bom_format": "csv_with_mpn",
        "requires_alternates": True,
        "special_assembly": True
    },
    "macrofab": {
        "bom_format": "online_portal",
        "component_sourcing": "macrofab_only"
    },
    "jlcpcb": {
        "bom_format": "jlcpcb_csv",
        "component_sourcing": "jlcpcb_parts"
    }
}

Prevent Common Issues

Component Availability

  • Check availability before submitting to CM: Save yourself the headache and check before you submit.
  • Pre-approved alternates included in BOM: Always have a plan B, and C, and D...
  • Availability alerts if stock changes: Get notified immediately if something goes out of stock.

Version Control

  • Unique revision numbers: Keep things straight with unique identifiers.
  • Git-tracked manufacturing files: Version control for the win!
  • Change log for each revision: Know exactly what changed and why.

Clear Specifications

  • No ambiguity in assembly requirements: Be crystal clear.
  • Pre-answer common CM questions: Anticipate their needs and answer before they ask.
  • Reference photos for tricky assembly: A picture is worth a thousand words.

Success Criteria

  • ✅ Complete manufacturing package generator
  • ✅ CM-specific profiles (JLCPCB, Screaming Circuits, MacroFab)
  • ✅ Zero back-and-forth with CM on documentation
  • ✅ Component availability verification before submission
  • ✅ Pre-approved alternates system

Priority

🟡 Important for professional use

Related Issues

#179 (Test fixture generator) #175 (Management reporting - manufacturing status) #68 (DFM agent)
