PyPSA Energy Balance Filtering Bug: The Curious Case of the 'Residential' Prefix

Hey everyone! Today, we're diving deep into a fascinating bug discovered in PyPSA (Python for Power System Analysis), specifically affecting energy balance filtering. This issue arises when the nice_names feature is enabled, causing a mismatch in bus carrier names due to an unexpected 'residential' prefix. Let's break down what happened, why it's important, and how it impacts your PyPSA projects.

The Problem: A Mismatch in Bus Carrier Names

So, here's the deal. After running PyPSA-EUR, it was observed that the n.statistics.energy_balance function stumbled when trying to filter by certain heat bus carrier names. This only happened when nice_names were enabled (which is the default setting, by the way). Some heat bus carriers—think names like "rural heat," "urban decentral heat," and "urban central heat"—were showing up in the energy balance display with a "residential " prefix. For example, "rural heat" became "residential rural heat."

Now, here's where things get tricky. When you tried to filter using these displayed nice names, like n.statistics.energy_balance(bus_carrier="residential rural heat"), you'd get a ValueError. The error message would claim that the bus carrier wasn't in the network. But wait a minute! The energy balance table itself was showing those exact names. What's going on?

The root cause, as it turns out, lies in how Groupers.bus_carrier works. This function calls self.carrier(n, "Bus", nice_names=nice_names). The intention behind nice_names is to make component carriers look pretty for presentation purposes. However, applying it to bus carriers? That's where the trouble starts. It actually mutates the canonical bus.carrier identifiers. These identifiers are crucial for internal filtering and unit lookup (using NetworkDescriptorsMixin.bus_carrier_unit). The result? A mismatch between what you see and what PyPSA uses internally, leading to that pesky ValueError.

In simpler terms, the residential prefix, while making the display names more user-friendly, was actually breaking the filtering mechanism under the hood. This is like giving someone a nickname that the system doesn't recognize – it might sound nice, but it won't work for official purposes!

Reproducing the Issue: A Step-by-Step Guide

Want to see this bug in action? Here's how you can reproduce it:

  1. Build the PyPSA-EUR network: If you're already working with PyPSA-EUR, you're one step ahead. If not, you'll need to set it up.

  2. Run the test configuration: Use the config/test/config.myopic.yaml configuration file. Alternatively, you can create a network where carriers have nice_name mappings that add that problematic "residential " prefix for heat carriers.

  3. Run the energy balance calculation with filtering: With the default settings (meaning nice_names=True), execute the following code:

    n.statistics.energy_balance(bus_carrier="residential rural heat")

  4. Witness the error: You should see the dreaded ValueError: Bus carriers {'residential rural heat'} not in network.

It's important to note that this isn't just a theoretical problem. It directly impacts anyone relying on energy balance filtering in PyPSA, especially when dealing with heat bus carriers and the nice_names feature. The versions tested and confirmed to be affected are PyPSA v1.0.2 and PyPSA-EUR v2025.07.0.

The Expected Behavior: Filtering Should Work!

Now, let's talk about what should happen. When you use n.statistics.energy_balance(bus_carrier="<nice_name bus.carrier>"), it should work flawlessly for filtering. You should be able to filter by the displayed bus carrier name without encountering a ValueError. This is crucial for accurate analysis and reporting of energy flows within your PyPSA model.

Think of it this way: you should be able to use the name you see on the report to filter the data. If the system shows "residential rural heat", you should be able to use that exact phrase to filter without the system throwing a fit. This makes the tool intuitive and reliable for users.

Why This Matters: The Importance of Accurate Filtering

So, why is this bug so important? Well, accurate filtering is fundamental to understanding the results of your PyPSA simulations. The energy balance is a key metric for assessing the performance of your energy system model. It tells you how much energy is being generated, consumed, and exchanged between different parts of the system. If you can't filter this information correctly, you're essentially flying blind.

Imagine you're trying to analyze the contribution of rural heat to the overall energy balance. You use the energy_balance function and try to filter by "residential rural heat". If the filtering fails, you won't get the accurate picture. You might underestimate or overestimate the role of rural heat, leading to incorrect conclusions and potentially flawed decisions about your energy system.

Furthermore, this issue highlights the subtle but significant impact of user interface features on core functionality. The nice_names feature, intended to improve the user experience, inadvertently introduced a bug that affects the accuracy of the analysis. This is a valuable reminder that even seemingly minor changes can have far-reaching consequences in complex software systems.

Diving Deeper: The Technical Details for the Curious Minds

For those of you who love to get into the nitty-gritty details, let's delve a bit deeper into the technical aspects of this bug. As mentioned earlier, the core of the problem lies in the Groupers.bus_carrier function and its interaction with nice_names. To truly understand the issue, we need to look at how PyPSA handles carrier names and filtering internally.

PyPSA uses a hierarchical system for naming carriers. Each carrier has a canonical name, which is the official identifier used within the code. This canonical name is typically a simple, unambiguous string like "gas" or "solar". However, for presentation purposes, carriers can also have nice names. These nice names are designed to be more user-friendly and might include spaces, special characters, or prefixes like "residential ".

The nice_names feature essentially maps the canonical carrier names to their corresponding nice names. This mapping is used when displaying information to the user, such as in tables and charts. The intention is to make the output more readable and understandable.

However, the bug arises because this mapping is being applied too early in the process. Specifically, it's being applied to the bus.carrier attribute before the filtering is performed. This means that the filtering is being done on the nice names rather than the canonical names. And since the internal filtering mechanisms rely on the canonical names, the mismatch occurs.

To fix this, the nice_names mapping should be applied only at the presentation stage, not during the filtering stage. The filtering should always be done using the canonical carrier names. This would ensure that the filtering is accurate and consistent, regardless of whether nice_names is enabled or not.

Solutions and Workarounds: What Can You Do Now?

Okay, so we've identified the problem and understand its implications. But what can you do about it right now? Here are a few potential solutions and workarounds:

  1. Disable nice_names: The simplest workaround is to disable the nice_names feature altogether. This will prevent the residential prefix from being added to the bus carrier names, and the filtering should work correctly. However, this means you'll lose the user-friendly display names in your reports and charts. You can set nice_names=False in your PyPSA configuration.
  2. Filter by canonical names: Instead of using the nice names, you can filter by the canonical carrier names directly. For example, instead of bus_carrier="residential rural heat", you would use bus_carrier="rural heat". This requires you to know the canonical names of the carriers you want to filter by, which might not always be obvious.
  3. Post-process the results: You can run the energy balance calculation without filtering and then post-process the results to filter by the nice names. This involves manually filtering the output table or data frame to extract the information you need. This is a more complex solution but gives you the most flexibility.
  4. Wait for a fix: The best long-term solution is to wait for a fix to be implemented in PyPSA. The PyPSA developers are aware of this issue and are likely working on a solution. Keep an eye on the PyPSA GitHub repository for updates and releases.

The Road Ahead: A Call for Collaboration and Testing

This bug highlights the importance of thorough testing and collaboration in software development. It also underscores the need for a clear separation of concerns between data representation and data processing. By identifying and addressing these kinds of issues, we can make PyPSA an even more robust and reliable tool for energy system analysis.

If you're a PyPSA user, I encourage you to test your workflows and report any issues you encounter. Your feedback is invaluable in helping the PyPSA developers improve the software. You can report bugs and suggest features on the PyPSA GitHub repository.

Let's work together to make PyPSA the best it can be! Happy modeling, everyone!
