Pandoc Lua: Unintuitive Figure Caption Handling With Inlines

Hey everyone, let's dive into a pretty tricky and often silent issue that can pop up when you're crafting powerful custom filters with Pandoc's Lua API. Specifically, we're talking about some rather unintuitive behavior when you try to pass Inlines as a caption to a Figure element. This isn't just a minor oversight; it can lead to frustrating debugging sessions, especially when your output looks fine in HTML but gets mangled in LaTeX or PDF. Understanding this distinction between Inlines and Blocks is absolutely crucial for anyone building robust Pandoc Lua filters. We're going to break down why this happens, how to spot it, and most importantly, how to fix it to ensure your figures always render perfectly, no matter the output format. So, grab your favorite beverage, and let's unravel this mystery together, because knowing these nuances will save you a ton of headaches down the line and elevate your Pandoc game significantly!

The Core Issue: When Inlines Go Rogue as Figure Captions

Alright, guys, let's get right to the heart of the matter: the unintuitive behavior you might encounter when passing Inlines where Blocks are expected for a Figure caption in Pandoc Lua filters. Picture this: you're building a super cool filter. Your specific use case involves taking div elements with a fig class and transforming them into proper Figure elements. The idea is simple enough – you want the first child of that div (if it's a Para) to serve as your figure's caption. Sounds straightforward, right? Well, here's where things can get a little wild, and frankly, a bit misleading. The initial assumption, often fueled by how flexible Pandoc's API can sometimes be with single elements, is that you can just pass a list of inlines directly as the caption. Many of us, myself included, might initially disembowel a Para element to extract its Inlines content, thinking that's what the Figure constructor expects for its caption argument. However, this is where the silent problem begins.

What happens next is truly unintuitive behavior. When you pass a list of inlines (like pdc.Inlines('Some caption text')) instead of a list of blocks (like pdc.Para('Some caption text')) to the Figure constructor, Pandoc's internal machinery kicks in, and it doesn't just reject it with an error. Oh no, that would be too easy! Instead, it performs a conversion that, while harmless in some output formats, becomes overtly problematic in others. Specifically, when converting to PDF via LuaLaTeX, you'll notice a peculiar phenomenon: whitespace in your caption text mysteriously disappears. Imagine a caption like "This is a great image" suddenly becoming "Thisisagreatimage." Pretty jarring, right? The reason this happens is fascinatingly subtle: the Figure constructor, when faced with an Inlines list, attempts to normalize it for its expected block structure. It effectively splits the Inlines on Str elements, putting each individual word into its own Plain element. This might seem like a minor detail, but it's a game-changer. For HTML output, this transformation is often invisible because browsers are generally forgiving with whitespace rendering in contiguous text. However, in the typeset world of LaTeX, every Plain element becomes a separate box, and the implicit spaces between words, which are normally handled by the text rendering engine, simply vanish because the structure is now seen as \texttt{This}\texttt{is}\texttt{a}\texttt{great}\texttt{image} rather than a single \caption{This is a great image}. This discrepancy makes the bug particularly insidious – it works just fine in one context, leading you to believe your code is solid, only to fail silently and visually in another. This silent unintuitive behavior is what makes debugging so difficult, as there’s no immediate error message to guide you. It's a prime example of why understanding the Abstract Syntax Tree (AST) and the exact expectations of Pandoc's constructors is so critical. We're essentially dealing with a mismatch between what we think we're providing and what the constructor actually requires, leading to unexpected and hard-to-trace formatting issues in the final output. The key takeaway here is that Figures are designed to contain block-level content for their captions, not raw Inlines, and misunderstanding this fundamental distinction can lead to significant headaches in your document generation workflow.

Diving Deeper: Understanding Pandoc's Figure Constructor

To truly grasp why this unintuitive behavior occurs with Pandoc's Lua Figure constructor, we need to take a closer look at how Pandoc's Abstract Syntax Tree (AST) is structured and what the Figure element expects. At its core, Pandoc processes documents by representing them as an AST, which is essentially a tree-like data structure that describes the document's content and structure. Different elements in this tree have specific requirements for their children or arguments. For instance, a Para (paragraph) element expects a list of Inlines (like text, bold words, links, etc.), while a BlockQuote expects a list of Blocks (like paragraphs, lists, code blocks). The crucial point here is that Pandoc makes a clear distinction between inline-level content and block-level content. Inlines are things that flow within a line of text, while Blocks are structural elements that typically begin on a new line and define a larger chunk of content.

Now, let's talk about the Figure constructor. When you're creating a figure, its caption isn't just any arbitrary text; it's a structural part of the document, designed to hold potentially complex content. Therefore, the Figure constructor, quite reasonably, expects its caption argument to be a list of blocks. This means it's looking for things like Para elements, Plain elements, or even BulletList elements to make up the caption. It's not expecting just a raw string or a flat list of Str elements. When you mistakenly provide a flat pdc.Inlines list (which is essentially a list of inline elements without any enclosing block structure), the Figure constructor doesn't throw an error. Instead, it tries to make sense of what you've given it in the context of its own expectations. This is where the silent and unintuitive part really kicks in. Internally, it performs a "normalization" where it takes those individual Str elements within your Inlines list and wraps each one in a Plain block. So, pdc.Inlines('Some caption text') effectively becomes something akin to [pdc.Plain('Some'), pdc.Plain('caption'), pdc.Plain('text')] from its perspective for the caption content. This is the root cause of the whitespace disappearance. In LaTeX, each Plain block often gets rendered as a distinct entity, and the natural inter-word spacing you'd expect between Str elements within a single Para or Plain block is lost because they are now separate block-level elements. It's like putting each word of a sentence in its own separate box, then stacking those boxes next to each other – the glue (spaces) that normally holds them together is gone.

This behavior contrasts sharply with how other constructors might handle partial content or single elements. Many Pandoc constructors are designed with a "Does What You Mean" (DWYM) philosophy, where if you pass a single string, it might automatically wrap it in a Str or a Para for you. This flexibility is incredibly convenient, but it also sets an expectation that isn't met by the Figure constructor's caption argument. Because it silently transforms Inlines into multiple Plain blocks rather than throwing an error or wrapping the entire Inlines list in a single Para block (which would be the DWYM approach many would expect), it creates a debugging nightmare. You get valid output in some formats (like HTML, where the visual impact is minimal), but incorrect output in others (like LaTeX/PDF), all without a clear indication of why. Understanding this internal conversion mechanism is paramount. It highlights that while Pandoc's API is powerful, you still need to be mindful of the expected type of content for each argument, especially when dealing with the fundamental distinction between Inlines and Blocks in the Pandoc AST. Ignoring this can lead to subtle yet significant rendering issues that are incredibly time-consuming to diagnose, reinforcing the need for careful API usage when constructing complex document elements like Figures.

Practical Implications and Reproducing the Behavior

Let's roll up our sleeves, guys, and really dig into the practical implications of this unintuitive behavior by walking through the provided Lua code example. This is where the theory hits the road, and you'll see firsthand how this Inlines vs. Blocks confusion can manifest as a silent bug in your Pandoc Lua filters. We're going to use a simple script to reproduce the behavior and observe the different outputs across various formats. The core of our example showcases the creation of a standard paragraph and then a figure caption using Inlines, which is precisely where the problem lies. The script starts by requiring the pandoc module, which is our gateway to Pandoc's powerful API and AST manipulation.

local pdc = require("pandoc")

local para = pdc.Para('Some para text')

local capt = pdc.Inlines('Some caption text')

for _, elem in ipairs({ para, capt }) do
  print(elem)
  print("")
end

local doc = pdc.Pandoc({ para, pdc.Figure({ }, capt) })

print(doc)
print("")

local formats = {
  'native',
  'html',
  'latex'
}

for _, fmt in ipairs(formats) do
  print(fmt)
  print(pdc.write(doc, fmt))
  print("")
end

First, we create a regular paragraph using pdc.Para('Some para text'). This is perfectly normal and will render as expected. Then, critically, we create our problematic caption: local capt = pdc.Inlines('Some caption text'). This line is the culprit, as we're explicitly creating a list of inlines where the Figure constructor expects blocks. The initial print(elem) loop is just to show you what these raw Pandoc elements look like in their string representation – you'll see Para "Some para text" and Inlines [Str "Some", Space, Str "caption", Space, Str "text"]. The Inlines representation clearly shows individual Str elements separated by Space elements. Now, for the main event: local doc = pdc.Pandoc({ para, pdc.Figure({ }, capt) }). Here, we construct a full Pandoc document, including our correct paragraph and, crucially, our Figure element. Notice how capt (our list of Inlines) is passed directly as the caption argument. The Figure constructor takes two main arguments: the list of Blocks that constitute the figure's content (empty in our example) and the Blocks for the caption. This is where the type mismatch occurs.

When print(doc) is executed, you'll get the native Pandoc AST representation of the entire document. If you inspect the Figure element within this output, you'll see something like Figure [] [Plain [Str "Some"], Plain [Str "caption"], Plain [Str "text"]]. This is the smoking gun! Instead of our Inlines being wrapped in a single Para block, they've been split into multiple Plain blocks, each containing a single word. This transformation is the root of our whitespace disappearance problem. Finally, the script iterates through different formats: native, html, and latex. For html output, if you run this, you'll likely see something like <p>Some para text</p><figure><figcaption>Some caption text</figcaption></figure>. Notice, the whitespace appears perfectly normal in HTML. This is because HTML rendering engines are generally robust and will re-add spaces between inline elements that are structurally separated but visually adjacent. However, when you write to latex, you'll get something like \caption{Somecaptiontext}. See that? All the spaces are gone! This demonstrates the problem perfectly. The latex writer sees [Plain [Str "Some"], Plain [Str "caption"], Plain [Str "text"]] and, treating each Plain as a distinct block, concatenates their content without inserting spaces, resulting in the mangled output. This explicit walk-through of the code and its outputs clearly illustrates the silent and unintuitive nature of this bug. It highlights that while your Lua code might execute without error, the subtle structural changes in the AST, particularly the implicit conversion of Inlines to multiple Plain blocks for the figure caption, can lead to significant and hard-to-diagnose rendering issues in specific output formats like LaTeX, reinforcing the importance of understanding the precise structure Pandoc expects for its various elements.

Best Practices: How to Properly Handle Figure Captions in Pandoc Lua Filters

Now that we've thoroughly dissected the unintuitive behavior and the underlying reasons for whitespace disappearance when using Inlines for Pandoc Lua figure captions, it's time to talk solutions and best practices. The good news is, fixing this is actually quite simple once you understand Pandoc's Abstract Syntax Tree (AST) and its expectations. The key takeaway, champs, is that a Figure element's caption must be a list of blocks, not a flat list of inlines. The most common and correct way to provide a simple text caption is to wrap your desired Inlines content within a Para block. This ensures that the caption is treated as a single, coherent paragraph, preserving all its internal spacing and formatting.

Let's look at how you can properly handle figure captions in your Pandoc Lua filters. Instead of directly passing pdc.Inlines('Some caption text'), you should always create a Para element that contains those inlines. Here’s the corrected approach:

local pdc = require("pandoc")

-- Correct way to create a caption:
local correct_caption_inlines = pdc.Inlines('This is the **correct** caption text.')
local correct_caption_block = pdc.Para(correct_caption_inlines)

-- Or even simpler, if your caption is just plain text:
local simpler_caption_block = pdc.Para('Another correct caption example.')

-- Original problematic way (for contrast):
local problematic_caption_inlines = pdc.Inlines('Some problematic caption text.')

-- Constructing the document with the correct caption
local doc_correct = pdc.Pandoc({ pdc.Figure({}, {correct_caption_block}) })

-- Constructing the document with the simpler correct caption
local doc_simpler = pdc.Pandoc({ pdc.Figure({}, {simpler_caption_block}) })

-- And the problematic one for comparison, notice the `capt` here is Inlines
local doc_problematic = pdc.Pandoc({ pdc.Figure({}, problematic_caption_inlines) })

print("--- Correct Caption (explicit Inlines wrapped in Para) ---")
print(pdc.write(doc_correct, 'native'))
print(pdc.write(doc_correct, 'latex'))
print("")

print("--- Correct Caption (simple Para string) ---")
print(pdc.write(doc_simpler, 'native'))
print(pdc.write(doc_simpler, 'latex'))
print("")

print("--- Problematic Caption (raw Inlines) ---")
print(pdc.write(doc_problematic, 'native'))
print(pdc.write(doc_problematic, 'latex'))
print("")

In the correct_caption_block example, we first create Inlines (which can contain bold text, italics, links, etc.) and then explicitly wrap them in a pdc.Para element. When you pass this pdc.Para (within a list, as the Figure caption expects a list of blocks) to the Figure constructor, Pandoc correctly interprets it as a single block-level caption. The native output for doc_correct will show Figure [] [Para [Str "This", Space, Str "is", Space, Str "the", Space, Strong [Str "correct"], Space, Str "caption", Space, Str "text."]], which is exactly what we want. The latex output will then correctly render as \caption{This is the \textbf{correct} caption text.}, preserving all whitespace and formatting. Even simpler, if your caption is just plain text without any complex inline formatting, you can directly pass a string to pdc.Para, and Pandoc will automatically convert it into Inlines wrapped in a Para for you, as shown with simpler_caption_block. This is a very common and efficient way to create simple paragraph captions.

Beyond Para, you can include other block elements in your caption list if your use case demands it. For instance, a caption could theoretically contain a list (BulletList, OrderedList) or a code block (CodeBlock) if that were ever relevant for your document's semantics. The key is always to provide a list of Blocks. My personal advice for Pandoc Lua filter development is to always be explicit about the type of element you are constructing, especially when dealing with fundamental structural differences like Inlines versus Blocks. If you're unsure, consult the Pandoc Lua API documentation or experiment with pdc.read and pdc.write to native format for smaller chunks of content. This helps you visualize the AST and confirm that your filter is generating the correct structure. By adopting these best practices, you’ll avoid those subtle, unintuitive bugs that lead to whitespace disappearance and ensure your figures and their captions render consistently and beautifully across all your target formats. It's about being proactive and understanding the building blocks of your document at a deeper level, making your filters much more robust and reliable.

Why This Matters: The Importance of Explicit API Behavior

Okay, guys, let's zoom out a bit and talk about why this seemingly small detail of Pandoc Lua's figure caption handling with Inlines versus Blocks is actually a big deal. This isn't just about a single unintuitive behavior; it speaks to the broader importance of explicit API behavior and clear communication in software design. When an API behaves silently in an unexpected way, especially by performing an implicit conversion that leads to data loss or corruption (like our whitespace disappearance), it creates a debugging nightmare. Imagine spending hours, or even days, trying to figure out why your beautifully styled LaTeX PDF isn't rendering correctly, only to find that your HTML output is perfectly fine. This inconsistency is a prime example of a silent bug, which are arguably the hardest types of issues to diagnose because there’s no error message, no crash, just a subtle visual distortion. Your code runs, it produces output, but that output isn't what you intended.

The value of clear documentation and error messages cannot be overstated here. If the Figure constructor either explicitly stated in its documentation that it requires a list of blocks for captions, or even better, threw a clear error when it received a list of Inlines, it would save countless developers from this frustrating experience. The current silent conversion to multiple Plain blocks, while perhaps done with the best intentions of being flexible, instead creates an unintuitive behavior that deviates from the "Does What You Mean" principle that often guides modern API design. Developers naturally expect that if an API can't handle a given input, it should either attempt a sensible default conversion (like wrapping the entire Inlines list in a single Para block, which would preserve structure and meaning) or, failing that, signal an error immediately. This explicit feedback loop is crucial for efficient development.

Moreover, this scenario highlights the power and also the potential pitfalls of working with Abstract Syntax Trees (ASTs) directly, as we do with Pandoc Lua filters. While direct AST manipulation offers incredible flexibility and power, it also places a greater responsibility on the developer to understand the precise structure and type expectations of each AST element. Without that deep understanding, subtle type mismatches can lead to cascading issues. For maintainers and developers of tools like Pandoc, issues like this spark important discussions within the community contributions regarding API design. It's moments like these that often lead to improvements, whether through enhanced documentation, more robust input validation, or a re-evaluation of implicit conversion strategies. When someone like @tarleb (who is often involved in the Lua API) sees these discussions, it provides valuable real-world feedback on developer experience. Ultimately, ensuring explicit API behavior by either enforcing strict type checking with clear errors or implementing predictable and non-destructive implicit conversions is vital for fostering a positive developer experience. It reduces cognitive load, speeds up debugging, and helps build a more reliable and understandable ecosystem for everyone using and extending powerful tools like Pandoc. This isn't just about a syntax detail; it's about making complex document processing accessible and manageable for a wider audience, enabling us all to build more robust and reliable automated publishing workflows. So, while this whitespace disappearance bug is a pain, it's a valuable lesson in API design and the importance of truly understanding your tools.

Conclusion

Alright, folks, we've covered a lot of ground today, diving deep into the often unseen and unintuitive behavior of Pandoc's Lua API when it comes to handling figure captions. We've seen how passing a list of Inlines directly to a Figure constructor, instead of the expected list of Blocks, can lead to a sneaky whitespace disappearance bug, particularly when rendering to LaTeX or PDF. This silent bug is a prime example of why understanding the nuances of Pandoc's Abstract Syntax Tree (AST), and the precise expectations of its constructors, is absolutely critical for anyone developing robust Pandoc Lua filters.

We broke down why this happens: the Figure constructor implicitly converts those raw Inlines into multiple Plain blocks, effectively stripping away the natural spacing. We then walked through a practical example, demonstrating how this unintuitive behavior manifests in different output formats, working seemingly fine in HTML but failing silently in LaTeX. Most importantly, we laid out the best practices: always wrap your caption Inlines in a pdc.Para element (or another appropriate block type) to ensure Pandoc treats it as a single, coherent block-level caption. By doing so, you explicitly provide the structure Pandoc expects, guaranteeing consistent and correct rendering across all your target formats.

Remember, guys, clarity in API design and explicit understanding of data structures save countless hours of debugging. This journey from a frustrating silent bug to a clear solution underscores the importance of digging into the details of your tools. Keep these insights in mind as you continue to build amazing things with Pandoc. Happy filtering, and may your documents always render perfectly!
