MCP OAuth Compatibility Problems: Scope & Auth

by SLV Team 47 views

Introduction: The OAuth Challenge in MCP Clients

Hey guys, let's dive into a critical issue affecting the integration of Model Context Protocol (MCP) clients with OAuth-enabled MCP servers. We're talking about compatibility problems, specifically around how these clients handle OAuth scopes and authentication when Dynamic Client Registration (DCR) is enabled. Major clients like Claude Code, Google Gemini CLI, and GitHub Copilot are experiencing difficulties. This limits the potential of Nextcloud MCP servers to work seamlessly with these tools in OAuth mode. It's a real headache for those of us trying to leverage OAuth for secure and efficient workflows.

Impact on Nextcloud MCP Server: Why This Matters

So, why should we care? Well, the Nextcloud MCP server's OAuth mode is currently experimental, as the README.md clearly states. This means it's not quite ready for prime time, and these compatibility issues are a major reason why. If you're trying to use OAuth with Claude Code, Gemini CLI, or Copilot, you might hit a wall with authentication failures. What's worse, if you're in an enterprise environment using providers like Azure AD/Entra ID, Okta, or others, you're facing additional hurdles. This is also independent of the upstream Nextcloud issues related to Bearer token support.

Diving Deep: The Root Causes of the Problems

Let's get into the nitty-gritty and look at the core issues:

1. The DCR Dilemma: Dynamic Client Registration Requirements

First off, Claude Code needs DCR to play nice, according to RFC 7591. But here's where things get tricky:

  • Enterprise OAuth providers, such as Azure AD and Okta, often don't support DCR. Yikes.
  • Even when DCR is supported, providers often want pre-provisioned API keys to access the registration endpoint. It's a catch-22.
  • Clients, unfortunately, don't always give you a way to specify a client ID/secret manually as a fallback.

Example: If you try to integrate with Azure AD, you'll probably see this error message:

AADSTS70011: The provided request must include a 'scope' input parameter.
The provided value for the input parameter 'scope' is not valid.

2. The Scope Parameter Snafu: Scope Parameter Issues

Okay, next up is the scope parameter. MCP clients aren't always sending the right scopes when DCR is enabled:

  • Sometimes, they skip the scope parameter altogether. Oops!
  • Other times, the scope values are just plain wrong.
  • There isn't a solid standard for MCP servers to tell clients what scopes they need.

Impact: Authorization servers reject requests because the scopes are missing or invalid.

3. The OAuth Discovery Failures: OAuth Discovery Failures

Clients have serious trouble figuring out the OAuth configuration:

  • Gemini CLI: Can't pull resource_metadata from the WWW-Authenticate header, and it tries the wrong discovery endpoint (.well-known/oauth-authorization-server instead of following the resource_metadata URL).
  • Claude Code: Immediately jumps to /.well-known/oauth-authorization-server and ignores the resource_metadata header.
  • Inconsistent handling of RFC 8414 (OAuth Authorization Server Metadata) and RFC 9728 (OAuth Protected Resource Metadata).

4. Architectural Design Issues: Architectural Design Issues

Currently, the MCP auth setup treats MCP servers like OAuth authorization servers. This means that every MCP server has to implement a bunch of things:

  • Discovery endpoints
  • Registration endpoints
  • Authorization endpoints
  • Token endpoints

Proposed solution: Treat MCP servers as OAuth resource servers, using existing identity providers/authorization servers. This is outlined in modelcontextprotocol/modelcontextprotocol#205.

Upstream Issues: Where the Real Problems Lie

Let's look at the bigger picture and what the MCP specification and client repositories are saying:

MCP Specification Repository

Claude Code Repository

Google Gemini CLI Repository

FastMCP Repository

Technical Deep Dive: More Details on the Problems

Let's get into some technical specifics:

OAuth Discovery Mechanisms

The MCP specification has multiple OAuth discovery methods, but clients mess up the implementation:

  1. RFC 9728 - OAuth 2.0 Protected Resource Metadata: The server sends a WWW-Authenticate header with a resource_metadata URL.
  2. RFC 8414 - OAuth Authorization Server Metadata: Discovery at /.well-known/oauth-authorization-server.

GitHub MCP Server example: The server might send this header:

WWW-Authenticate: Bearer error="invalid_request",
  error_description="No access token was provided in this request",
  resource_metadata="https://api.githubcopilot.com/.well-known/oauth-protected-resource/mcp"

Gemini CLI can't figure this out and tries the wrong endpoint.

Scope Communication Problem

  • OAuth servers need to know which scopes to grant.
  • The MCP spec doesn't define standard scopes.
  • Clients don't have a way to find out which scopes are needed from the MCP server.
  • Some clients don't send a scope parameter at all with DCR.

Provider Compatibility Matrix

Here's a quick look at how different providers stack up:

Provider DCR Support Status Notes
Azure AD/Entra ID ❌ No Broken Requires pre-registration, fixed redirect URIs
Okta ⚠️ Requires API Key Broken DCR endpoint needs admin credentials
AWS Cognito ❌ No Broken Requires custom implementation with Lambda/API Gateway
Auth0 ✅ Yes May work DCR supported (requires testing)
Keycloak ✅ Yes May work DCR supported (requires testing)
GitHub ❌ Special Complex Uses RFC 9728, but clients fail to discover properly

Potential Solutions: Ideas from the Community

Here are some community-proposed solutions:

SEP-991: Client ID Metadata Documents

  • Allow OAuth clients to use HTTPS URLs as client identifiers.
  • The URL points to a JSON document with client metadata.
  • Addresses scenarios where servers and clients don't have a pre-existing relationship.
  • Enables servers to trust clients based on verified metadata.

SEP-1299: Simplified Flow

  • Move OAuth flow management from MCP clients to MCP servers.
  • Use HTTP Message Signatures for session binding.
  • Resource servers could leverage existing authorization methods.

Resource Server Pattern

  • Treat MCP servers as OAuth resource servers, not authorization servers.
  • Use existing identity providers/authorization servers.
  • The MCP server validates tokens but doesn't issue them.
  • Supports token exchange flows for on-behalf-of scenarios.

Status and Recommendations: What You Should Do

Current State

  • ⚠️ OAuth mode in this Nextcloud MCP server is EXPERIMENTAL.
  • 🔴 Not recommended for production because of:
    1. Client compatibility issues (the problem we're discussing).
    2. Nextcloud upstream issues (#209).
    3. Limited enterprise OAuth provider support.

Short-term Workarounds

  • ✅ Use Basic Auth mode (recommended) - it works reliably with all clients.
  • ⚠️ For OAuth testing: Use providers with full DCR support (Auth0, Keycloak).
  • ⚠️ Avoid enterprise providers (Azure AD, Okta) until client-side issues are fixed.

Long-term

  • 🕒 Monitor upstream MCP client repositories for OAuth improvements.
  • 🕒 Watch for SEP-991 and SEP-1299 standardization progress.
  • 🕒 Track Nextcloud user_oidc Bearer token support (#209).
  • 🕒 Consider implementing the resource server pattern when clients support it.

References: Where to Learn More

Here are some resources to get you started:

Blog Posts & Documentation

MCP Specification

This is a tracking issue. I'll add updates as upstream issues progress and client implementations improve. Stay tuned!"
