Fixing STM32F429I-DISC1 LVGL Demo Issues

by SLV Team 41 views

Hey everyone! Today, we're diving deep into troubleshooting a common issue faced by developers using the STM32F429I-DISC1 board with LVGL (Light and Versatile Graphics Library) demos. Specifically, we're addressing the problem where LVGL demos that previously worked flawlessly in Zephyr RTOS v4.2.1 stopped functioning after a particular commit. This can be a real headache, especially when you're trying to showcase your graphical user interface or test out new features. Let's break down the problem, the steps to reproduce it, and how we can potentially resolve it.

Understanding the Bug: STM32F429I-DISC1 and LVGL Demos

When dealing with embedded systems, getting your display up and running is crucial. The STM32F429I-DISC1 is a popular development board known for its robust capabilities, including a built-in LCD. LVGL is a fantastic open-source graphics library that allows developers to create stunning user interfaces on microcontrollers. Combining these two should, in theory, lead to a smooth development experience. However, as with all things in the world of software and hardware, hiccups can occur.

The reported bug highlights a regression, meaning something that used to work has stopped working. In this case, the LVGL demos found in the zephyr/samples/modules/lvgl/demos directory within the Zephyr RTOS project were functioning correctly up until commit 011a357db09118fa31ecb3a1986238e097cc7ed9. Post this commit, the display remains blank, effectively rendering the demos unusable. It's worth noting that while the screen is blank, the UART shell remains responsive, suggesting that the system hasn't completely crashed but rather the graphical output is failing. This distinction is vital for pinpointing the root cause.

The Importance of Regression Testing

This situation underscores the significance of regression testing in software development. Regression testing involves re-running tests after code changes to ensure that new modifications haven't inadvertently broken existing functionality. In an embedded systems context, where hardware and software are tightly coupled, regressions can be particularly insidious. They might stem from subtle changes in memory management, peripheral initialization, or even timing-critical sections of code. Identifying the exact commit that introduced the regression, as done using git bisect in this case, is a crucial first step in the debugging process.

Steps to Reproduce the Issue

To effectively troubleshoot a bug, you need to be able to reproduce it consistently. Here’s how to reproduce the issue with the STM32F429I-DISC1 and LVGL demos:

  1. Navigate to the Demos Directory:

    • Open your terminal and change the directory to zephyr/samples/modules/lvgl/demos. This is where the LVGL demo applications reside within the Zephyr RTOS project structure.

  2. Build the Project:

    • Use the west build command to compile the application for the STM32F429I-DISC1 board. The command is: west build -b stm32f429i_disc1 .. The west build tool is part of the Zephyr development environment and simplifies the build process.

  3. Flash the Firmware:

    • Once the build is successful, flash the generated firmware to the board using west flash. This command transfers the compiled code to the STM32F429I-DISC1's flash memory, allowing the microcontroller to execute it upon reset.

By following these steps, you can replicate the bug and confirm whether you're experiencing the same issue. If the screen remains blank after flashing, you've successfully reproduced the problem, and we can move on to digging deeper into potential solutions.

Impact and Severity

The impact of this bug is classified as a “Showstopper.” This is a critical designation, indicating that the issue prevents the use of major functionality and renders the system essentially unusable for its intended purpose. A blank screen on a device designed to display graphical information is a severe impediment. It hinders further development, testing, and demonstration of LVGL-based applications on the STM32F429I-DISC1 platform. Therefore, resolving this issue is of paramount importance.

Environment Details

Knowing the environment in which the bug occurs is vital for effective debugging. Here are the key environmental factors in this case:

  • Operating System: Arch Linux
    • The host operating system can sometimes influence the behavior of embedded development tools and the build process.
  • Toolchain: SDK 0.17.4
    • The software development kit (SDK) version provides critical information about the compiler, linker, and other tools used to build the firmware. Different SDK versions might include varying compiler optimizations, libraries, and header files, which could impact the final result.
  • Commit SHA: 011a357db09118fa31ecb3a1986238e097cc7ed9
    • As identified by git bisect, this commit is the point at which the regression was introduced. Knowing the specific commit allows us to examine the code changes made in that commit and identify the potential cause of the issue.

Analyzing the Commit

The commit SHA 011a357db09118fa31ecb3a1986238e097cc7ed9 is the key to unlocking this mystery. The next step is to examine the changes introduced in this commit. This might involve:

  • Checking the Commit Message: The commit message often provides a brief description of the changes made.
  • Diffing the Code: Using git diff, we can compare the code before and after the commit to see exactly what lines were added, removed, or modified.
  • Focusing on Relevant Areas: Since the issue involves the display, we should pay close attention to changes related to the LCD driver, LVGL integration, memory management (especially framebuffers), and clock configurations.

Potential Causes and Debugging Strategies

Based on the information available, here are some potential causes for the blank screen issue and debugging strategies we can employ:

  1. LCD Driver Issues:

    • Cause: Changes in the LCD driver initialization or configuration might be preventing the display from being properly set up.
    • Debugging:
      • Carefully review the LCD driver code in the problematic commit.
      • Check for any modifications to the initialization sequence, clock settings, or GPIO configurations.
      • Use a debugger to step through the driver initialization and see if any errors occur.
      • Verify that the correct LCD panel is being detected and configured.

  2. LVGL Integration Problems:

    • Cause: Modifications to the LVGL integration layer (the code that connects LVGL to the Zephyr RTOS and the LCD driver) might be causing issues.
    • Debugging:
      • Inspect the LVGL initialization code and ensure that it's being called correctly.
      • Check the framebuffer configuration and memory allocation for LVGL.
      • Look for any changes in the LVGL tick handling or display flushing mechanisms.
      • Use LVGL's built-in debugging tools (if available) to monitor its internal state.

  3. Memory Management Conflicts:

    • Cause: A memory management issue, such as a memory leak or incorrect memory allocation, could be corrupting the framebuffer or other critical data structures.
    • Debugging:
      • Use memory analysis tools to detect potential leaks or corruption.
      • Examine the code for any dynamic memory allocation (e.g., malloc) and ensure that memory is being freed correctly.
      • Check the size and alignment of the framebuffer and other buffers used by LVGL and the LCD driver.

  4. Clock Configuration Errors:

    • Cause: Changes in the clock configuration could affect the timing of the LCD controller or the LVGL rendering process.
    • Debugging:
      • Review the clock initialization code and verify that the correct frequencies are being set for the LCD and other peripherals.
      • Check for any clock-related dividers or multipliers that might have been modified.
      • Use a debugger to monitor the clock frequencies and ensure they are within the expected ranges.

  5. Concurrency and Synchronization Issues:

    • Cause: If multiple threads or interrupts are accessing the LCD or LVGL resources, synchronization issues (e.g., race conditions) could lead to data corruption or other problems.
    • Debugging:
      • Use RTOS-aware debugging tools to inspect thread states and synchronization primitives (e.g., mutexes, semaphores).
      • Look for any critical sections that are not properly protected by synchronization mechanisms.
      • Consider using a real-time analysis tool to identify potential timing issues.

Next Steps: Diving Deeper

To effectively resolve this issue, we need to systematically investigate each of these potential causes. This will involve:

  1. Examining the Code Changes: Carefully review the code changes introduced in commit 011a357db09118fa31ecb3a1986238e097cc7ed9, paying close attention to the areas mentioned above.
  2. Using a Debugger: Connect a debugger to the STM32F429I-DISC1 board and step through the code, observing the state of variables, registers, and memory.
  3. Adding Logging Statements: Strategically insert logging statements into the code to trace the execution flow and identify potential error points.
  4. Isolating the Problem: Try to isolate the issue by disabling or modifying specific parts of the code to see if it resolves the problem.
  5. Seeking Community Help: If you're stuck, don't hesitate to reach out to the Zephyr and LVGL communities for assistance. Others might have encountered similar issues and can offer valuable insights.

Conclusion
