Hey guys! Let's dive into the fascinating world of capacitors and figure out how to calculate the charge (q), energy (e), and voltage (v) for each one in a circuit. We'll be working with a specific example to make things super clear. This is a common problem in physics, especially when dealing with electrical circuits. Understanding how capacitors behave is crucial, so let's get started. We'll break down the process step-by-step, making sure you grasp the concepts easily. This guide will cover the necessary formulas and how to apply them to find all the unknowns. So grab your calculators and let's go!

The Problem: Setting the Stage

Alright, here’s the scenario we're dealing with. We have a circuit with several capacitors connected in a specific way, and a voltage source. The goal is to determine the charge, energy, and voltage across each capacitor. Let's make sure we have all the information correct, which is as follows:

  • Voltage Source: 24V
  • Capacitors:
    • C1 = 2F (Farads)
    • C2 = 3F
    • C3 = 6F
    • C4 = 2F
    • C5 = 1F

Our task is to find the charge (q), energy (e), and voltage (v) for each capacitor (C1 through C5). This involves understanding how capacitors behave when connected in series and parallel, and how they store energy. The key here is to use the right formulas and apply them methodically. Ready to begin? Let's get to it!

Step 1: Analyzing the Circuit and Simplifying

First things first, we need to understand how the capacitors are connected. In this example, the circuit layout isn't explicitly provided, but we can assume a typical configuration to illustrate the calculation process. Generally, to find the equivalent capacitance and simplify the circuit, we have to recognize the series and parallel connections in order to calculate the total capacitance of the entire circuit. Based on common circuit configurations, we can typically simplify the circuit step by step until the total capacitance is found.

Combining Capacitors in Series

When capacitors are connected in series, the reciprocal of the total capacitance (C_total) is equal to the sum of the reciprocals of individual capacitances. The formula is:

1/C_total = 1/C1 + 1/C2 + ...

Combining Capacitors in Parallel

When capacitors are connected in parallel, the total capacitance (C_total) is simply the sum of individual capacitances. The formula is:

C_total = C1 + C2 + ...

Once the total capacitance is found, the total charge in the circuit and the equivalent voltage can be calculated. These two steps lay the groundwork for calculating the properties of each individual capacitor.

Step 2: Calculating the Equivalent Capacitance

To determine the charge, energy, and voltage of each capacitor, let's assume the following simplified circuit configuration. In our scenario, C1 and C2 are in parallel, and this combination is in series with C3, and finally, all of this is in parallel with C4 and C5. We'll calculate the equivalent capacitance step by step.

Parallel Combination of C1 and C2

Since C1 and C2 are in parallel, their equivalent capacitance (C12) is:

C12 = C1 + C2 = 2F + 3F = 5F

Series Combination with C3

The combination of C12 (5F) is in series with C3 (6F). So, the equivalent capacitance (C123) is:

1/C123 = 1/C12 + 1/C3 = 1/5 + 1/6 = 11/30

Therefore, C123 = 30/11 F ≈ 2.73F

Parallel Combination with C4 and C5

C123 is in parallel with both C4 and C5. The total equivalent capacitance (C_total) is:

C_total = C123 + C4 + C5 = 30/11 + 2 + 1 = 63/11 F ≈ 5.73F

Now, we have the total equivalent capacitance for the whole circuit. We can proceed to calculate the total charge.

Step 3: Calculating the Total Charge and Voltage

With the total capacitance and the voltage from the source, we can calculate the total charge stored in the circuit. The total charge (Q_total) can be found using the following formula:

Q_total = C_total * V

Where:

  • C_total is the total equivalent capacitance (63/11 F)
  • V is the source voltage (24V)

So, Q_total = (63/11) * 24 ≈ 137.45 Coulombs.

Since we now have the total charge, it is also possible to calculate the voltage in different sections of the circuit. The calculations are necessary to proceed to the individual properties of the capacitors.

Step 4: Calculating the Voltage Across Each Capacitor

This is where it gets interesting! Let's go through each capacitor to determine its voltage. Remember that capacitors in parallel have the same voltage, and capacitors in series share the charge.

Voltage across C1, C2 and C12

Since C4 and C5 are in parallel, the voltage across them is the same as the voltage across the combination of C1, C2, and C3. To find this voltage (V123), use the formula:

V123 = Q123 / C123

Where Q123 is the charge across the C123 combination.

The charge across the equivalent capacitor C123 can be calculated as:

Q123 = Q_total - Q4 - Q5.

Where:

  • Q_total is the total charge across the equivalent capacitor circuit (137.45 Coulombs)
  • Q4 is the charge across C4
  • Q5 is the charge across C5

Q4 = C4 * V = 2 * 24 = 48 Coulombs

Q5 = C5 * V = 1 * 24 = 24 Coulombs

Therefore,

Q123 = 137.45 - 48 - 24 = 65.45 Coulombs.

V123 = 65.45 / 2.73 = 23.98 V.

As you can see, the voltage across C1 and C2 is the same.

Voltage across C3

Since C12 and C3 are in series, the voltage across C3 (V3) can be calculated by using the total voltage across the C12 and C3. The total voltage for C1 and C2 are approximately equal to the source voltage, with the voltage drops across the series elements.

Voltage across C4 and C5

Since C4 and C5 are in parallel with the source voltage, the voltage across each capacitor (V4 and V5) is the same as the source voltage, which is 24V.

Step 5: Calculating the Charge on Each Capacitor

Now, let's calculate the charge on each capacitor using the formula:

q = C * V

Charge on C1

The charge on C1 (Q1) is:

Q1 = C1 * V1 = 2F * 23.98V ≈ 47.96 Coulombs

Charge on C2

The charge on C2 (Q2) is:

Q2 = C2 * V2 = 3F * 23.98V ≈ 71.94 Coulombs

Charge on C3

The charge on C3 (Q3) is:

Q3 = C3 * V3 = 6F * 23.98V ≈ 143.88 Coulombs

Charge on C4

The charge on C4 (Q4) is:

Q4 = C4 * V4 = 2F * 24V = 48 Coulombs

Charge on C5

The charge on C5 (Q5) is:

Q5 = C5 * V5 = 1F * 24V = 24 Coulombs

Step 6: Calculating the Energy Stored in Each Capacitor

Finally, let's calculate the energy stored in each capacitor. The energy (E) stored in a capacitor can be calculated using the following formulas:

E = 0.5 * C * V^2

or

E = 0.5 * Q * V

or

E = 0.5 * Q^2 / C

Let's apply these formulas to our capacitors.

Energy Stored in C1

E1 = 0.5 * C1 * V1^2 = 0.5 * 2F * (23.98V)^2 ≈ 575.04 Joules

Energy Stored in C2

E2 = 0.5 * C2 * V2^2 = 0.5 * 3F * (23.98V)^2 ≈ 862.56 Joules

Energy Stored in C3

E3 = 0.5 * C3 * V3^2 = 0.5 * 6F * (23.98V)^2 ≈ 1725.12 Joules

Energy Stored in C4

E4 = 0.5 * C4 * V4^2 = 0.5 * 2F * (24V)^2 = 576 Joules

Energy Stored in C5

E5 = 0.5 * C5 * V5^2 = 0.5 * 1F * (24V)^2 = 288 Joules

Conclusion: Recap and Key Takeaways

And there you have it, folks! We've successfully calculated the charge, energy, and voltage for each capacitor in the circuit. Here's a quick summary:

  • C1: q ≈ 47.96 C, e ≈ 575.04 J, v ≈ 23.98 V
  • C2: q ≈ 71.94 C, e ≈ 862.56 J, v ≈ 23.98 V
  • C3: q ≈ 143.88 C, e ≈ 1725.12 J, v ≈ 23.98 V
  • C4: q = 48 C, e = 576 J, v = 24 V
  • C5: q = 24 C, e = 288 J, v = 24 V

Key Formulas to Remember:

  • Charge (q): q = C * V
  • Energy (e): e = 0.5 * C * V^2
  • Capacitance (Series): 1/C_total = 1/C1 + 1/C2 + ...
  • Capacitance (Parallel): C_total = C1 + C2 + ...

Understanding these formulas and how to apply them is essential for any electrical engineering or physics enthusiast. Keep practicing, and you'll become a pro in no time! If you have any questions, feel free to ask. Thanks for joining, and happy calculating!

Disclaimer: Please note that the circuit configuration was assumed for demonstration purposes. Real-world circuits may have different configurations.
